DeWALT

DeWALT DW505 1/2 in. (13mm) VSR™ Dual-Range Hammer Drill

Product variants

DeWALT DW505 1/2 in. (13mm) VSR™ Dual-Range Hammer Drill

Complete tough applications with a powerful motor and lightweight design on the 1/2 in. (13mm) VSR™ Dual-Range Hammer Drill. Featuring dual speeds, this versatile drill delivers control for a wide range of jobs.

Features:

7.8 amp motor provides high performance and overload protection
High/low gear for high speed drilling or high toque applications
Dual mode: hammerdrill/drill for wood, steel or masonry applications

Applications:

Ideal for installation and removal of Tapcon®/Tapper™ fasteners

Optimal drilling applications in concrete from 3/16" to 3/8"

Maximum drilling applications in concrete of 1/2"

Drilling applications in wood up to 1 1/2"

Drilling applications in steel up to 1/2"

Ideal for small Spike®/Redi-Drive™ and "nail-in" anchor systems in block, brick, and soft concrete

Additional Features:

Lightweight design for easy use and handling in a variety of orientations
Two-finger trigger for increased comfort
360-degree side handle with depth rod offers greater control, versatility, and increased depth accuracy
Variable speed allows for precise hole placement on work surface

Specifications:

Amps [A]	7.8
Capacity (Steel) [in]	0.5
Chuck Size [in]	1/2
Chuck Size [mm]	13
Chuck Type	Keyed
Color	Black, Yellow
Has Lock On Switch?	Yes
Has Reverse?	Yes
Has Secondary Handle?	Yes
Has Variable Speed?	Yes
Is it a Set?	No
Max. Drilling Capacity (Masonry) [in]	1/2
Max. Drilling Capacity (Masonry) [mm]	19
Max. Drilling Capacity (Metal) [in]	1/2
Max. Drilling Capacity (Metal) [mm]	13
Max. Drilling Capacity (Steel) [in]	1/2
Max. Drilling Capacity (Wood) [in]	1-1/2
Max. Drilling Capacity (Wood) [mm]	38
Power Output [W]	800
Power Source	Corded
Power [W]	300
Product Height [in]	13
Product Length [in]	9
Product Weight [oz]	76.8
Product Width [in]	4
Tool Length [in]	13
Tool Weight [lbs]	4.8
